Series | MELSERVO-J4 MELSERVO-J5 |
---|---|
Type | LM-U2 |
Side | PRIMARY |
Power supply capacity (kVA) | 0,5 |
Rated Current (A) | 0,9 |
Maximum current (A) | 2,7 |
Rated thrust (N) | 50 |
Maximum thrust (N) | 150 |
Maximum Speed (m/s) | 2 |
Magnetic attraction force (N) | 0 |
Protection Class | IP00 |
Cooling method | NATURAL |
Lenght (mm) | 130 |
Width (mm) | 24,5 |
---|---|
Height (mm) | 66,5 |
Depth (mm) | 130 |
Weight (kg) | 0,3 |
